聚[2-甲氧基-5-(2-乙基己氧基)-1,4-苯乙炔]，Poly[2-methoxy-5-(2-ethylhexyloxy)-1,4-phenylenevinylene] [MEH-PPV]；average Mn 40,000-70,000

描述

Band gap: 2.3 eV

质量水平

100

分子量

average M_n 40,000-70,000

荧光

λ_ex 493 nm; λ_em 554 nm in toluene

轨道能量

HOMO -5.3 eV
LUMO -3 eV

OLED设备性能

ITO/PEDOT:PSS/MEH-PPV/Al

• Color: orange-red
• Max. Luminance: 220 Cd/m²
• Max. EQE: 0.3 %
• Turn-On Voltage: 3.8 V

ITO/PEDOT:PSS/MEH-PPV/PBO/Al

• Color: orange-red
• Max. Luminance: 970 Cd/m²
• Max. EQE: 1.9 %
• Turn-On Voltage: 2.9 V

ITO/PEDOT:PSS/MEH-PPV/PBZT/Al

• Color: orange-red
• Max. Luminance: 1400 Cd/m²
• Max. EQE: 2.5 %
• Turn-On Voltage: 2.8 V

OPV设备性能

ITO/MEH-PPV/BBL/Al

• Short-circuit current density (J_sc): 1.98 mA/cm²
• Open-circuit voltage (V_oc): 0.93 V
• Fill Factor (FF): 0.47
• Power Conversion Efficiency (PCE): 1.1 %

ITO/MEH-PPV:PC61BM(1:4)/Ca

• Short-circuit current density (J_sc): 2 mA/cm²
• Open-circuit voltage (V_oc): 0.8 V
• Fill Factor (FF): 0.25
• Power Conversion Efficiency (PCE): 1.5 %

M_w/M_n

~6

储存温度

2-8°C
